Karras pre-conditioning

Author

Benedict Thekkel

import timm, torch, random, datasets, math, fastcore.all as fc, numpy as np, matplotlib as mpl, matplotlib.pyplot as plt
import k_diffusion as K, torchvision.transforms as T
import torchvision.transforms.functional as TF,torch.nn.functional as F

from torch.utils.data import DataLoader,default_collate
from pathlib import Path
from torch.nn import init
from fastcore.foundation import L
from torch import nn,tensor
from datasets import load_dataset
from operator import itemgetter
from torcheval.metrics import MulticlassAccuracy
from functools import partial
from torch.optim import lr_scheduler
from torch import optim

from fastAIcourse.datasets import *
from fastAIcourse.conv import *
from fastAIcourse.learner import *
from fastAIcourse.activations import *
from fastAIcourse.init import *
from fastAIcourse.sgd import *
from fastAIcourse.resnet import *
from fastAIcourse.augment import *
from fastAIcourse.accel import *
from fastprogress import progress_bar
from diffusers import UNet2DModel, DDIMPipeline, DDPMPipeline, DDIMScheduler, DDPMScheduler
torch.set_printoptions(precision=5, linewidth=140, sci_mode=False)
torch.manual_seed(1)
mpl.rcParams['image.cmap'] = 'gray_r'
mpl.rcParams['figure.dpi'] = 70

import logging
logging.disable(logging.WARNING)

set_seed(42)
if fc.defaults.cpus>8: fc.defaults.cpus=8
xl,yl = 'image','label'
name = "fashion_mnist"
n_steps = 1000
bs = 512
dsd = load_dataset(name)
@inplace
def transformi(b): b[xl] = [F.pad(TF.to_tensor(o), (2,2,2,2))*2-1 for o in b[xl]]

tds = dsd.with_transform(transformi)
dls = DataLoaders.from_dd(tds, bs)

dl = dls.train
xb,yb = b = next(iter(dl))
# sig_data = xb.std()
sig_data = 0.66

y is clean signal, n is N(0,1) noise.

def scalings(sig):
    totvar = sig**2+sig_data**2
    # c_skip,c_out,c_in
    return sig_data**2/totvar,sig*sig_data/totvar.sqrt(),1/totvar.sqrt()

sig_samp = (torch.randn([10000])*1.2-1.2).exp()
plt.hist(sig_samp);

import seaborn as sns
sns.kdeplot(sig_samp, clip=(0,10));

def noisify(x0):
    device = x0.device
    sig = (torch.randn([len(x0)])*1.2-1.2).exp().to(x0).reshape(-1,1,1,1)
    noise = torch.randn_like(x0, device=device)
    c_skip,c_out,c_in = scalings(sig)
    noised_input = x0 + noise*sig
    target = (x0-c_skip*noised_input)/c_out
    return (noised_input*c_in,sig.squeeze()),target
def collate_ddpm(b): return noisify(default_collate(b)[xl])
def dl_ddpm(ds): return DataLoader(ds, batch_size=bs, collate_fn=collate_ddpm, num_workers=8)
dls = DataLoaders(dl_ddpm(tds['train']), dl_ddpm(tds['test']))
dl = dls.train
(noised_input,sig),target = b = next(iter(dl))
show_images(noised_input[:25], imsize=1.5, titles=fc.map_ex(sig[:25], '{:.02f}'))

show_images(target[:25], imsize=1.5, titles=fc.map_ex(sig[:25], '{:.02f}'))

noised_input.mean(),noised_input.std(),target.mean(),target.std()
(tensor(-0.69019), tensor(1.01665), tensor(-0.40007), tensor(1.03293))

Train

class UNet(UNet2DModel):
    def forward(self, x): return super().forward(*x).sample
def init_ddpm(model):
    for o in model.down_blocks:
        for p in o.resnets:
            p.conv2.weight.data.zero_()
            for p in fc.L(o.downsamplers): init.orthogonal_(p.conv.weight)

    for o in model.up_blocks:
        for p in o.resnets: p.conv2.weight.data.zero_()

    model.conv_out.weight.data.zero_()
lr = 1e-2
epochs = 25
opt_func = partial(optim.Adam, eps=1e-5)
tmax = epochs * len(dls.train)
sched = partial(lr_scheduler.OneCycleLR, max_lr=lr, total_steps=tmax)
cbs = [DeviceCB(), MixedPrecision(), ProgressCB(plot=True), MetricsCB(), BatchSchedCB(sched)]
model = UNet(in_channels=1, out_channels=1, block_out_channels=(32, 64, 128, 256), norm_num_groups=8)
init_ddpm(model)
learn = Learner(model, dls, nn.MSELoss(), lr=lr, cbs=cbs, opt_func=opt_func)
learn.fit(epochs)
loss epoch train
0.703 0 train
0.348 0 eval
0.263 1 train
0.224 1 eval
0.201 2 train
0.197 2 eval
0.188 3 train
0.186 3 eval
0.179 4 train
0.179 4 eval
0.172 5 train
0.174 5 eval
0.169 6 train
0.165 6 eval
0.160 7 train
0.167 7 eval
0.158 8 train
0.161 8 eval
0.154 9 train
0.164 9 eval
0.152 10 train
0.151 10 eval
0.151 11 train
0.153 11 eval
0.147 12 train
0.150 12 eval
0.147 13 train
0.150 13 eval
0.145 14 train
0.146 14 eval
0.143 15 train
0.144 15 eval
0.142 16 train
0.144 16 eval
0.141 17 train
0.141 17 eval
0.140 18 train
0.141 18 eval
0.139 19 train
0.140 19 eval
0.139 20 train
0.140 20 eval
0.138 21 train
0.138 21 eval
0.137 22 train
0.137 22 eval
0.137 23 train
0.139 23 eval
0.137 24 train
0.137 24 eval

# torch.save(learn.model, 'models/fashion_karras.pkl')
# model = learn.model = torch.load('models/fashion_karras.pkl').cuda()
def denoise(target, noised_input): return target*c_out + noised_input*c_skip
with torch.no_grad():
    sigr = sig.cuda().reshape(-1,1,1,1)
    c_skip,c_out,c_in = scalings(sigr)
    targ_pred = learn.model((noised_input.cuda(),sig.cuda()))
    x0_pred = denoise(targ_pred, noised_input.cuda()/c_in)
show_images(noised_input[:25], imsize=1.5, titles=fc.map_ex(sig[:25], '{:.02f}'))

show_images(x0_pred[:25].clamp(-1,1), imsize=1.5, titles=fc.map_ex(sig[:25], '{:.02f}'))

show_images(denoise(target.cuda(), noised_input.cuda()/c_in)[:25], imsize=1.5, titles=fc.map_ex(sig[:25], '{:.02f}'))

sig_r = tensor(80.).cuda().reshape(-1,1,1,1)
c_skip,c_out,c_in = scalings(sig_r)
x_r = torch.randn(32,1,32,32).to(model.device)*sig_r
with torch.no_grad():
    targ_pred = learn.model((x_r*c_in,sig_r.squeeze()))
    x0_pred = denoise(targ_pred, x_r)
show_images(x0_pred[:25], imsize=1.5)

x0_pred.max(),x0_pred.min(),x0_pred.mean(),x0_pred.std()
(tensor(0.63882, device='cuda:0'),
 tensor(-1.18548, device='cuda:0'),
 tensor(-0.54164, device='cuda:0'),
 tensor(0.43493, device='cuda:0'))

Sampling

from miniai.fid import ImageEval
cmodel = torch.load('models/data_aug2.pkl')
del(cmodel[8])
del(cmodel[7])

bs = 2048
tds = dsd.with_transform(transformi)
dls = DataLoaders.from_dd(tds, bs, num_workers=fc.defaults.cpus)

dt = dls.train
xb,yb = next(iter(dt))

ie = ImageEval(cmodel, dls, cbs=[DeviceCB()])
sz = (512,1,32,32)
sz = (2048,1,32,32)
def sigmas_karras(n, sigma_min=0.01, sigma_max=80., rho=7., device='cpu'):
    ramp = torch.linspace(0, 1, n)
    min_inv_rho = sigma_min**(1/rho)
    max_inv_rho = sigma_max**(1/rho)
    sigmas = (max_inv_rho + ramp * (min_inv_rho-max_inv_rho))**rho
    return torch.cat([sigmas, tensor([0.])]).to(device)
sk = sigmas_karras(100)
plt.plot(sk);

def denoise(model, x, sig):
    c_skip,c_out,c_in = scalings(sig)
    return model((x*c_in, sig))*c_out + x*c_skip
def get_ancestral_step(sigma_from, sigma_to, eta=1.):
    if not eta: return sigma_to, 0.
    var_to,var_from = sigma_to**2,sigma_from**2
    sigma_up = min(sigma_to, eta * (var_to * (var_from-var_to)/var_from)**0.5)
    return (var_to-sigma_up**2)**0.5, sigma_up
@torch.no_grad()
def sample_euler_ancestral(x, sigs, i, model, eta=1.):
    sig,sig2 = sigs[i],sigs[i+1]
    denoised = denoise(model, x, sig)
    sigma_down,sigma_up = get_ancestral_step(sig, sig2, eta=eta)
    x = x + (x-denoised)/sig*(sigma_down-sig)
    return x + torch.randn_like(x)*sigma_up
@torch.no_grad()
def sample_euler(x, sigs, i, model):
    sig,sig2 = sigs[i],sigs[i+1]
    denoised = denoise(model, x, sig)
    return x + (x-denoised)/sig*(sig2-sig)
@torch.no_grad()
def sample_heun(x, sigs, i, model, s_churn=0., s_tmin=0., s_tmax=float('inf'), s_noise=1.):
    sig,sig2 = sigs[i],sigs[i+1]
    n = len(sigs)
    gamma = min(s_churn/(n-1), 2**0.5-1) if s_tmin<=sig<=s_tmax else 0.
    eps = torch.randn_like(x) * s_noise
    sigma_hat = sig * (gamma+1)
    if gamma > 0: x = x + eps * (sigma_hat**2-sig**2)**0.5
    denoised = denoise(model, x, sig)
    d = (x-denoised)/sig
    dt = sig2-sigma_hat
    x_2 = x + d*dt
    if sig2==0: return x_2
    denoised_2 = denoise(model, x_2, sig2)
    d_2 = (x_2-denoised_2)/sig2
    d_prime = (d+d_2)/2
    return x + d_prime*dt
def sample(sampler, model, steps=100, sigma_max=80., **kwargs):
    preds = []
    x = torch.randn(sz).to(model.device)*sigma_max
    sigs = sigmas_karras(steps, device=model.device, sigma_max=sigma_max)
    for i in progress_bar(range(len(sigs)-1)):
        x = sampler(x, sigs, i, model, **kwargs)
        preds.append(x)
    return preds
# preds = sample_lms(model, steps=20, order=3)
# preds = sample(sample_euler_ancestral, model, steps=100, eta=0.5)
preds = sample(sample_euler, model, steps=100)
# preds = sample(sample_heun, model, steps=20, s_churn=0.5)
100.00% [20/20 00:09<00:00]
s = preds[-1]
s.min(),s.max()
(tensor(-1.08955, device='cuda:0'), tensor(1.46819, device='cuda:0'))
show_images(s[:25].clamp(-1,1), imsize=1.5)

# euler 100
ie.fid(s),ie.kid(s),s.shape
(5.231043207481207, 0.0031656520441174507, torch.Size([2048, 1, 32, 32]))
# euler 100
ie.fid(s),ie.kid(s),s.shape
(5.406003616592329, 0.015411057509481907, torch.Size([2048, 1, 32, 32]))
# ancestral 100 0.5
ie.fid(s),ie.kid(s),s.shape
(5.452807558586642, 0.0071729626506567, torch.Size([2048, 1, 32, 32]))
# heun 50
ie.fid(s),ie.kid(s),s.shape
(6.221842673288506, 0.023713070899248123, torch.Size([2048, 1, 32, 32]))
# heun 20
ie.fid(s),ie.kid(s),s.shape
(5.610681075267394, -0.005569742992520332, torch.Size([2048, 1, 32, 32]))
# heun 20, churn 0.5
ie.fid(s),ie.kid(s),s.shape
(5.2517917311790825, 0.026914160698652267, torch.Size([2048, 1, 32, 32]))
# lms 20
ie.fid(s),ie.kid(s),s.shape
(5.061003587997561, 0.019381564110517502, torch.Size([2048, 1, 32, 32]))
# reals
ie.fid(xb)
2.5736580178430586
from scipy import integrate
def linear_multistep_coeff(order, t, i, j):
    if order-1 > i: raise ValueError(f'Order {order} too high for step {i}')
    def fn(tau):
        prod = 1.
        for k in range(order):
            if j == k: continue
            prod *= (tau-t[i-k]) / (t[i-j]-t[i-k])
        return prod
    return integrate.quad(fn, t[i], t[i+1], epsrel=1e-4)[0]
@torch.no_grad()
def sample_lms(model, steps=100, order=4, sigma_max=80.):
    preds = []
    x = torch.randn(sz).to(model.device)*sigma_max
    sigs = sigmas_karras(steps, device=model.device, sigma_max=sigma_max)
    ds = []
    for i in progress_bar(range(len(sigs)-1)):
        sig = sigs[i]
        denoised = denoise(model, x, sig)
        d = (x-denoised)/sig
        ds.append(d)
        if len(ds) > order: ds.pop(0)
        cur_order = min(i+1, order)
        coeffs = [linear_multistep_coeff(cur_order, sigs, i, j) for j in range(cur_order)]
        x = x + sum(coeff*d for coeff, d in zip(coeffs, reversed(ds)))
        preds.append(x)
    return preds
